Jacoco xml report imported but coverage still 0%

Template for a good bug report, formatted with Markdown:

  • versions used (SonarQube, Scanner, Plugin, and any relevant extension)
    Apache Maven 3.5.4
    Java version: 1.8.0_144
    Sonar Version 8.4.1
    Jacoco maven plugin 0.8.5
    Jacoco sonar plugin
  • error observed (wrap logs/code around triple quote ``` for proper formatting)
    The coverage is displayed as 0% in sonar.
  • steps to reproduce
    I build a eclipse application with tycho. It’s a multi module application.
    I have unit tests on specific modules (ask by tycho)
    I have a coverage report module with a xml report generated and not empty and a html report with the good value
    Sonar parse it:
    INFO] Sensor JaCoCo XML Report Importer [jacoco]
    [INFO] Importing 1 report(s). Turn your logs in debug mode in order to see the exhaustive list.
    [INFO] Sensor JaCoCo XML Report Importer [jacoco] (done) | time=70ms

I check in debug mode and the report is the good one.

So my conclusion is it’s due to inclusions/exclusions. but i put empty element in my parent pom and nothing is change.

Any idea?


	<!-- Code coverage by unit tests -->

Just to add more information.
The build have note the same parent for build and for unit test and sonar build.
- coverage.parent
- coverage report
- child1
- child1.test
- child2
- child3
- child3.test

I do:
mvn clean install -f product/pom.xml
mvn clean verify -f product/coverage.parent/pom.xml
mvn sonar:sonar -f product/coverage.parent/pom.xml

I create a merge request to have more logs and better understand what can happen.


Welcome to the community!

Starting with your first post, you really don’t need to specify exclusions/inclusions for most Maven projects. I would strip those properties out of the pom IIWY.

You haven’t actually specified your version of SonarQube. That would be helpful.

Also, it would be helpful to post your code-formatted (``` on the line before and on the line after) analysis logs.


Sorry it’s my sonar qube version. I don’t fix my sonar maven plugin.

With my path:
i have the log:
[INFO] 19:14:41.732 Coverage report '/home/builder/jenkins_workspace/....coverage.report/target/site/jacoco-aggregate/jacoco.xml' could not locate source file MiscCachedInformation.java in package my/package/model.

So the locator don’t find the file according to this line:


I appreciate your willingness to contribute a PR. Unfortunately, even if it’s accepted, the next release isn’t expected until the end of Sept. (early Oct. if I’m being realistic).

So could you provide your full analysis logs?



sorry for the delay but i try many fix and debug the sensor. It seem to be due because of our folder structure. The jacoco sensor plugin don’t find the source file.

I find a reproducer (i simply fork an existing repo and step by step go to our structure):

I do to commit. One to reach a case where sonar fill the coverage.
mvn clean install -Pjacoco
mvn sonar:sonar -Dsonar.coverage.jacoco.xmlReportPaths=$PWD/example.tests.report/target/site/jacoco-aggregate/jacoco.xml

And it’s works! But…

I do another commit which change the structure and the command line to reach my real project structure :
mvn clean install -f releng/coverage.parent/pom.xml -Pjacoco
mvn sonar:sonar -f releng/coverage.parent/pom.xml -Dsonar.coverage.jacoco.xmlReportPaths=$PWD/example.tests.report/target/site/jacoco-aggregate/jacoco.xml

I try with sonar 8.4.2 on my laptop:
In both case the jacoco report (xml and html) is well (with a coverage).
But sonar don’t detect it and display a 0% coverage in the second case and seems to not find any source code.

I do a diff on log:
diff.log (30.5 KB)

For information it works if we go from root:
mvn sonar:sonar -Dsonar.coverage.jacoco.xmlReportPaths=$PWD/example.tests.report/target/site/jacoco-aggregate/jacoco.xml

Based on this, I found a way to pass throught the bug. Instead of using a sub project as root module for coverage. I use a pom_coverage.xml in the root directory. And it’s works perfectly.
